b) Lift the coin-cell battery out of the system board.
Installing the coin cell battery
1. Place the coin-cell battery into its slot on the system board.
2. Press the coin-cell battery with positive (+) side facing up until the release latch springs back into place and secures it to the system
board.
3. To install:
a) side cover
4. Follow the procedure in After working inside your computer.
System fan
Removing the System fan
1. Follow the procedure in Before working inside your computer .
2. Remove the:
a) side cover
b) air shroud
Removing and installing components
53
