Dell Precision 7680 - Installing the memory module

Steps
1. Align the notch on the memory module with the tab on the memory-module slot.
2. Slide the memory module firmly into the slot at an angle and press the memory module down until it clicks into place.
Next steps
1. Install the base cover.
2. Follow the procedure in after working inside your computer.
Memory interposer board
Removing the interposer board module
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
3. Remove the memory module.
About this task
NOTE: For models shipped with a SODIMM configuration.
The figure indicates the location of the interposer board module and provides a visual representation of the removal procedure.
34
Removing and installing components
