9. Palm rest 10. Display assembly
11. Speakers 12. SD card reader
13. Coin-cell battery 14. Power-adapter cable
15. CAMM memory bracket 16. CAMM connector module
17. Solid-state drive 18. Solid-state drive shield
19. Discrete GPU 20. Fingerprint reader board
21. Power button 22. Power-button board
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
Base cover
Removing the base cover
Prerequisites
1. Follow the procedure in before working inside your computer.
About this task
The figure indicates the location of the base cover and provides a visual representation of the removal procedure.
14
Removing and installing components
