Delta AS Series Manual

Chapter 5 Analog Input/Output Module AS06XA
5- 3
5_
5.2 Specifications and Functions
5.2.1 Specifications
 Electrical specifications
Module Name AS06XA-A
Number of Analog
Inputs/Outputs
4 inputs
2 outputs
Analog-to-Digital
Conversion
Voltage input/Current input/Voltage output/Current output
Supply Voltage 24 VDC (20.4–28.8 VDC) (-15% to +20%)
Connector Type
Removable terminal block
Conversion Time
2ms/channel
Isolation
An analog circuit is isolated from a digital circuit by a digital integrated circuit/
optocoupler, but the analog channels are not isolated from one another.
Isolation between a digital circuit and the ground: 500 VDC
Isolation between an analog circuit and the ground: 500 VDC
Isolation between an analog circuit and a digital circuit: 500 VDC
Isolation between the 24 VDC and the ground: 500 VDC
Weight
145 g
 Functional specifications for the analog-to-digital conversion
Analog-to-Digital
Conversion
Voltage Input
Rated Input Range -10 V ~ +10 V 0 V ~ 10 V ±5 V 0 V ~ 5 V 1 V ~ 5 V
Rated Conversion Range
K-32000
~
K32000
K0
~
K32000
K-32000
~
K32000
K0
~
K32000
K0
~
K32000
Hardware Input Limit*
1
-10.12V
~
10.12V
-0.12V
~
10.12V
-5.06V
~
5.06V
-0.06V
~
5.06V
0.95V
~
5.05V
Conversion Limit*
2
K-32384
~
K32384
K-384
~
K32384
K-32384
~
K32384
K-384
~
K32384
K-384
~
K32384
Error Rate Room Temperature: ±0.2% ; Full Temperature Range: ±0.5%
Hardware Resolution 16 bits
Input Impedance 2MΩ
Absolute Input Range*
3
±15 V

Delta AS Series Specifications

General

Series	AS Series
Power Supply	24VDC
Cooling Method	Natural convection
Programming Language	Function Block Diagram (FBD)
Communication Interface	Ethernet, RS-232, RS-485
Output Voltage	24V DC
Output Current	2A
Operating Temperature	55°C
Storage Temperature	70°C
Protection Features	Overvoltage
Certifications	CE, UL
