Page #161 background imageLoading...
Page #161 background image
Chapter 6 Temperature Measurement Module AS04/06RTD
6- 3
6_
6.2 Specifications and Functions
6.2.1 Specifications
Electrical specifications
Module AS04RTD-A AS06RTD-A
Number of Analog
Inputs
4 6
Applicable Sensor
2-Wire & 3-Wire Pt100/Ni100/Pt1000/Ni1000/JPt100/LG-Ni1000/Cu50/Cu100/0
300 Ω/03000 Ω
Pt100: DIN 43760-1980 JIS C1604-1989; 100 Ω 3850 PPM/°C
Pt1000: DIN EN60751; 1 kΩ 3850 PPM/°C
Ni100/Ni1000: DIN 43760
JPt100: JIS C1604-1989
LG-Ni1000
Cu50/Cu100
Supply Voltage 24 VDC (20.428.8 VDC) (-15% to +20%)
Connector Type Removable terminal block
Overall Accuracy
Pt100/Ni100/Pt1000/Ni1000/JPt100
25° C/77° F: The allowed error range is ±0.1% of full scale.
-20° C to 60° C/- F to 140° F: The allowed error range is ±0.5% of full scale.
LG-Ni1000; 25° C/77° F: The allowed error range is ±0.1% of full scale.
Cu50; 25° C/77° F: The allowed error range is ±4% of full scale.
Cu100; 25° C/77° F: The allowed error range is ±2% of full scale.
Conversion Time Two-wire/Three-wire configuration: 200 ms/channel
Isolation
An analog circuit is isolated from a digital circuit by a digital integrated circuit/
optocoupler, and the analog channels are isolated from one another by
optocouplers.
Isolation between a digital circuit and the ground: 500 VDC
Isolation between an analog circuit and the ground: 500 VDC
Isolation between an analog circuit and the digital circuit: 500 VDC
Isolation between the 24 VDC and the ground: 500 VDC
Weight 115 g 125 g
