13.5 IO-Link Event Code Table
Here is the table of IO-Link event codes which are recorded in Port1-4 Device Status of the Normal Exchange Area
page. If the sources of events are IO-Link devices, please also refer to the IO-Link device operation manual.
IO-Link
Event
Codes
Type
Event Solution
Source
Warning Error
Notifica-
tion
IO-Link
Master
IO-Link
Device
16#4000
V
Device temperature
over-load
Lower load
V
16#4210
V
Device temperature
over-run
Clear source of heat
V
16#5101
V
Device fuse blown
Change fuse
V
16#5110
V
Power supply voltage
over-run
Check tolerance
V
16#5111
V
Power supply voltage
under-run
Check tolerance
V
16#6320
V
Parameter error
Check device
specifications
V
16#6321
V
Parameter missing
Check device
specifications
V
16#7710
V
Device short circuit
Check installation
V
16#8C10
V
Process variable range
over-run
Check process data
V
16#8C20
V
Measurement range
over-run
Check application
V
16#8C30
V
Process variable range
under-run
Check process data
V
16#8CA0
V
No connected IO-Link
device
Check installation
V
16#8CA1
V
The version of the IO-
Link protocol is different
from the one
configured.
Use matching IODD file
and configured again.
V
16#8CA2
V
Connected device is
different from the one
configured in the
software
Check configurations and
installation
V
16#8CA3
Reserved
V
16#8CA4
16#8CAD
16#8CAE
V
IO-Link device process
cable short circuit
Check installation
V
16#8CA5
V
Master temperature
exceeds 135°C
Clear source of heat
V
16#8CA6
V
Master temperature
exceeds 160°C
Clear source of heat and
lower load
V
16#8CA7
V
Device power supply
voltage under-run L+
(<18V)
Check the external power
supply
V
