10.3 Profiles and Dimensions
10.3.1 AS-F232
37
23.9
59.3
66.3
Unit: mm
10.3.2 AS-F422/AS-F485/AS-F2AD/AS-F2DA
37
23.9
59.3
60.8
Unit: mm
10.3.3 AS-FCOPM
61.3
37
59.3
23.9
Unit: mm
