Delta AS Series Manual

Chapter 11 DeviceNet Master Scanner Module AS01DNET-A
11-7
1
1
11.3 DeviceNet Network Communication
11.3.1 Relationship between Transmission Distance and Baud Rate
The transmission distance of a DeivceNet network is determined by the baud rate. The following table shows the
corresponding maximum communication distance at different baud rates.
Baud rate (bits/s)
10K 20K 50K 125K 250K 500K 800K 1M
Max. transmission
distance (M)
5000 2500 1000 500 250 100 50 25
11.3.2 DeivceNet Network Topology Structure

Delta AS Series Specifications

General

Series	AS Series
Power Supply	24VDC
Cooling Method	Natural convection
Programming Language	Function Block Diagram (FBD)
Communication Interface	Ethernet, RS-232, RS-485
Output Voltage	24V DC
Output Current	2A
Operating Temperature	55°C
Storage Temperature	70°C
Protection Features	Overvoltage
Certifications	CE, UL
