AS Series Module Manual
10-8
10
Item
Specification
(Non-Connected Type, only
uses TCP connections)
CIP Objects
Identity Object (16#01)
Message Router Object (16#02)
Assembly Object (16#04)
Connection Manager Object (16#06)
Port Object (16#F4)
TCP/IP Interface Object (16#F5)
Ethernet Link Object (16#F6)
Not supporting self-defined objects
10.2.7.4 Topology
With its own standalone communication port, the AS-FEN02 card can work independently and can be MODBUS TCP
Server, Client and EtherNet/IP Adapter. After installing the extension card, use HWCONFIG in ISPSoft to configure the
communication.
Linear Topology
Star Topology
