Delta AS Series Manual

Chapter 8 Load Cell Module AS02LC
8- 17
8_
9. Recording channels
Record the input values of the cyclic sampling for each channel. The system saves up to 500 data points and
the recording time is 10 ms.
Instruction for recording Recordin g e nds
500 records o f d ata
Time
Valu e of the chan nel
8.2.6 Wiring
 External wiring
(Impedance: Less than 100 )
CH1
SIG+
SIG-
SEN+
SEN-
*1
Connected to
on a power supply module
System
ground
Third ground
EXC+
EXC-
SIG+
SIG-
SEN+
SEN-
EXC+
EXC-
A+5V
AGND
A+5V
AGND
0V
24V
DC/DC
converter
A+5V
AGND
Four-wire
Six-wire
CH2

Delta AS Series Specifications

General

Series	AS Series
Power Supply	24VDC
Cooling Method	Natural convection
Programming Language	Function Block Diagram (FBD)
Communication Interface	Ethernet, RS-232, RS-485
Output Voltage	24V DC
Output Current	2A
Operating Temperature	55°C
Storage Temperature	70°C
Protection Features	Overvoltage
Certifications	CE, UL
