AS Series Module Manual

8- 18

 Multiple load cells connected in parallel are connected to a single load cell module.

Lo ad cell

CH1

CH2

Lo ad cell

Loa d ce ll

Note 1: Please connect on the power supply module and on the load cell module to a system

ground, and then ground the system ground or connect the system ground to a distribution box.

Note 2: If multiple load cells are connected in parallel, the total impedance should be greater than 40 Ω.
