Chapter 5 Analog Input/Output Module AS06XA
5- 7
5_
Number Name Description
5 Clip For removing the terminal block
6 DIN Rail Clip Secures the module onto the DIN rail
7 Module Connecting Set Connects the modules
8 Ground Clip
9 Label Nameplate
5.2.3 Arrangement of Terminals
AS06XA-A
V1+ V2+
IO1 IO2
AG
0V
24V
VO1
I3+
VI3
VO2
I4+
VI4-
VI1
V3+
I1+
VI2-
V4+
I2+
06X A
-
-
PWR
ERR
A D
