Chapter 6 Temperature Measurement Module AS04/06RTD
6- 7
6_
CR# Name Description Atr. Defaults
19
Channel 3 filter average percentage
20
Channel 4 filter average percentage
21
Units of temperature
0: Fahrenheit
1: Celsius
R/W
0
22 Channel alarm setup
0: open channel alarm
1: close channel alarm
bit0: channel 1
bit1: channel 2
bit2: channel 3
bit3: channel 4
0: warning
1: alarm
bit8: error in the power supply
bit9: error in the module hardware
bit10: error in calibration
R/W
0
201 Instruction set
16#0101: record the peak value
again for channel 1
16#0102: record the peak value
again for channel 2
16#0104: record the peak value
again for channel 3
16#0108: record the peak value
again for channel 4
16#010F: record the peak values
again for channels 1–4
16#0201: enable recording for
channel 1
16#0202: enable recording for
channel 2
16#0204: enable recording for
channel 3
16#0208: enable recording for
W
0
