1.2.2.3 Conducted Immunity Test
Environmental Phenomenon
Fast Transient
Burst
High Energy
Surge
Radio
Frequency
Interference
Reference Standard IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-6
Interface/Port Specific Interface/Port Test Level Test Level Test Level
Data communication
Shielded cable 1 kV 1 kV CM 10 V
Unshielded cable 1 kV 1 kV CM 10 V
Digital and analog I/O
AC I/O (unshielded) 2 kV
2 kV CM
1 kV DM
10 V
Analog or DC I/O
(unshielded)
1 kV 1 kV CM 10 V
All shielded lines (earth) 1 kV 1 kV CM 10 V
Equipment power
AC power 2 kV
2 kV CM
1 kV DM
10 V
DC power 2 kV
0.5 kV CM
0.5 kV DM
10 V
I/O power and
auxiliary power output
AC I/O and AC auxiliary
power
2 kV
2 kV CM
1 kV DM
10 V
DC I/O and DC auxiliary
power
2 kV
0.5 kV CM
0.5 kV DM
10 V
