Delta AS Series Manual

AS Series Module Manual
7- 28
_7
CR#
Operand Function Description Defaults
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
601 631 661 691 721 751 781 811 SV SV Target value 0
602 632 662 692 722 752 782 812 PID_MODE
PID control
mode
0: automatic
control
When PID_MAN
is switched from
1 to 0, the
output value
(MV) is included
in the automatic
algorithm.
1: the parameters
are tuned
automatically for
the temperature
control. When
the tuning is
complete, the
device is
automatically
reset to 0, and
the parameters
Kc_Kp, Ti_K
i
,
Td_K
d
, and Tf
are set
appropriately.
0
603 633 663 693 723 753 783 813
PID_MAN
PID A/M
mode
0: auto; the MV is
output based
on the PID
algorithm.
1: manual; the MV
is output based
on the MOUT.
When
0

Delta AS Series Specifications

General

Series	AS Series
Power Supply	24VDC
Cooling Method	Natural convection
Programming Language	Function Block Diagram (FBD)
Communication Interface	Ethernet, RS-232, RS-485
Output Voltage	24V DC
Output Current	2A
Operating Temperature	55°C
Storage Temperature	70°C
Protection Features	Overvoltage
Certifications	CE, UL
