Delta AS Series Manual

AS Series Module Manual
7- 32
_7
CR#
Operand Function Description Defaults
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
is implemented.
Otherwise the
present error is
brought into the
PID algorithm
normally.
618 648 678 708 738 768 798 828 α value Integral sum
Range: 0–100
Unit: 0.01
31
619 649 679 709 739 769 799 829
β value Integral sum 0
620 650 680 710 740 770 800 830 MOUT
Manual
output value
(MOUT)
When PID_MAN is
set to 1, the MV
value is output as
this manual MOUT
value, between
MV_MAX and
MV_MIN.
Range: 0–1000
(0%–100%)
0
621 651 681 711 741 771 801 831 BIAS
Feedforward
output value
Feedforward
output value, used
for the PID
feedforward
0
622
623
652
653
682
683
712
713
742
743
772
773
802
803
832
833
MV
Output value
(MV)
A floating-point
number
Range: 0–100
Unit: %
--
624
625
654
655
684
685
714
715
744
745
774
775
804
805
834
835
I_MV
Accumulated
integral value
Floating-point
format.
The accumulated
integral value is
temporarily stored
for reference.
When the MV is
out of the range
--
