AS Series Module Manual

8- 26

Step 5: enter the command for activating the weight calibration 98 into D28007.

Step 6: put no load on the load cell (adjustment point 1) and enter 1 into D28007. 1 represents CH1 and 2

represents CH2.

Step 7: put a load on the load cell (adjustment point 2). For multi-point adjustment, repeat this step. This

example uses a 1 kg weight.

Step 8: to complete the adjustment, enter the command for deactivating the weight calibration 99 into

D28007.

A characteristic curve is shown below.

Dig ita l value

Point

1000 1 000 00

1 k g

10 kg

Adju sting two p oi nts

Weig ht
