AS Series Module Manual
9- 24
Using DHCP: Besides using IP Setting Tool to set the IP setting mode to DHCP mode, you can also use knob to
set the mode to DHCP.
When both ID1 and FORMAT 1 are set to 0 and both ID2 and FORMAT 2 are set to F, IP setting mode is
in DHCP mode. And then use Ethernet to connect with your computer.
Open EIP Builder and select IP Manager from the Tool on the tool bar.
Click Stop the Server and then select a suitable Network Interface. Click Start the Server to complete
the setting. After that, you need to turn the power OFF and then ON so that the devices will send DHCP
requests to the computer.
Check the device in the DHCP request form to assign the IP address to its corresponding MAC address.
You can also export the corresponding table. After the assignment is complete, you can see the result in
the status section.
After IP setting is complete, you can decide whether to disable DHCP function or not. If the system is in
the absence of a DHCP server (or use IP Setting Tool only for once), it is suggested to use IP Setting
Tool to change the IP setting mode to static mode. If the system includes a DHCP server, it is suggested
to keep the IP setting mode in DHCP mode. Whenever the power of the remote module is OFF, the
system clears all the IP parameters and sends DHCP request out whenever the power of the remote
module is ON to make sure the DHCP server is working.
