Delta AS Series Manual

Chapter 3 Analog Input Module AS04/08AD-A
3- 7
3_
CR# Name Description
Atr. Defaults
8: -20 mA to +20 mA
5
Channel 1 offset
Range: -32768 to +32767
R/W 0
6
Channel 2 offset
7
Channel 3 offset
8
Channel 4 offset
9
Channel 1 gain
Range: -32768 to +32767
R/W 1000
10
Channel 2 gain
11
Channel 3 gain
12
Channel 4 gain
13
Channel 1 average
times
Range: 1–100
R/W 10
14
Channel 2 average
times
15
Channel 3 average
times
16
Channel 4 average
times
17
Channel 1 filter
average percentage
Range: 0–3
Unit: ±10%
1: ±10%
2: ±20%
3: ±30%
R/W 1
18
Channel 2 filter
average percentage
19
Channel 3 filter
average percentage
20
Channel 4 filter
average percentage
21
Channel sampling
cycle
(sampling/integration
time)
0: 2 ms
1: 4 ms
2: 10 ms
3: 15 ms
4: 20 ms
5: 30 ms
R/W 0
