Delta ASDA-B2 Series User Manual

ASDA-B2 Chapter 10 Specifications
Revision May, 2018 10-3
ASDA-B2 Series
100W 200W 400W 750W 1kW 1.5kW 2kW 3kW
01 02 04 07 10 15 20 30
Environment
Vibration
9.80665 m/s
2
(1 G) less than 20 Hz,
5.88 m/ s
2
(0.6 G) 20 to 50 Hz
IP Rating IP20
Power System TN system
*4
Approvals
IEC/EN 61800-5-1, UL508C
Note:
*1. When it is in rated load, the speed ratio is: the minimum speed (smooth operation) / rated
speed.
*2. When the command is the rated speed, the velocity correction ratio is: (rotational speed with
no load – rotational speed with full load) / rated speed.
*3. TN system: The neutral point of the power system connects to the ground directly.
The exposed metal components connect to the ground via the protective earth conductor.
*4. Please refer to section 10.4 for overload features.

Delta ASDA-B2 Series Specifications

General

Control Mode	Position, Speed, Torque
Storage Temperature	-20°C to 65°C
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Output Power	0.1 kW to 3.0 kW
Communication Interface	RS-485, CANopen
Encoder Feedback	Incremental
Protection	Overvoltage, Overcurrent, Overload, Overheat
Operating Temperature	0°C to 55°C
Humidity	20% to 90% RH (non-condensing)
Vibration Resistance	5.9 m/s² (0.6G) at 10-55Hz
