ASDA-B2 Chapter 10 Specifications
Revision May, 2018
10-11
ECMA
C06 C08
04H 07H
Storage temperature (˚C) -10˚C ~ 80˚C
Operating humidity 20 ~ 90%RH (non-condensing)
Storage humidity 20 ~ 90%RH (non-condensing)
Vibration capacity 2.5G
IP Rating
IP65 (use the waterproof connector and shaft seal
installation (or oil seal)
Approvals
Note:
*1. The rated torque is the continuous permissible torque between 0 ~ 40˚C operating temperature
which is suitable for the following heat sink dimension.
ECMA-__04 / 06 / 08: 250 mm x 250 mm x 6 mm
ECMA-__10: 300 mm x 300 mm x 12 mm
ECMA-__13: 400 mm x 400 mm x 20 mm
ECMA-__18: 550 mm x 550 mm x 30 mm
Material: Aluminum – F40, F60, F80, F100, F130, F180
*2. The built-in brake of the servo motor is for remaining the item in stop status. Do not use it to
decelerate or as the dynamic brake.
*3. If desire to reach the max. torque limit of motor 250%, it is suggested to use the servo drive
with higher watt.
