Delta ASDA-B2 Series User Manual

Chapter 10 Specifications ASDA-B2
10-18 Revision May, 2018
ASD-B2-1021; ASD-B2L-1021; ASD-B2-1521 (1 kW ~ 1.5 kW)
SCREW: M4×0.7
MOUNTING SCREW TORQUE:14(kgf-cm)
70(2.76) 189.4(7.45)
Ø6(0.23)
GROUNDING
85.1(3.35)
74(2.91)
5(0.19)
WEIGHT
1.72 (3.79)
(1) Dimensions are in millimeters (inches); Weights are in kilograms (kg)
and (pounds (lbs)).
(2) Dimensions and weights of the servo drive may be revised without
prior notice.
NOTE

Delta ASDA-B2 Series Specifications

General

Control Mode	Position, Speed, Torque
Storage Temperature	-20°C to 65°C
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Output Power	0.1 kW to 3.0 kW
Communication Interface	RS-485, CANopen
Encoder Feedback	Incremental
Protection	Overvoltage, Overcurrent, Overload, Overheat
Operating Temperature	0°C to 55°C
Humidity	20% to 90% RH (non-condensing)
Vibration Resistance	5.9 m/s² (0.6G) at 10-55Hz
