4 Product overview
Scope of delivery
Installation and Operation Manual for Solar Power Inverter M70A EU V1.1 EN 2020-02-20
12
4.2 Overview of components and connections
1
2
3
4
9
10
8
7
6
5
Fig. 4.1: Overview of external components and connections
1 Air outlet 6 AC cable gland
2 Wi-Fi module (optional accessory) 7 Cable gland for RS485, digital inputs, dry contacts, external
power-o
3 DC isolating switch 1+2 8 Type plate
4 DC connector panel 9 Air inlet with fan module
5 Grounding connection 10 Sub-1G antenna
