4 Product overview
Cooling system
Installation and Operation Manual for Solar Power Inverter M70A EU V1.1 EN 2020-02-20
22
4.8.2 Internal fans
The internal fans circulate the air inside the inverter to prevent
heat buildup.
Fig. 4.18: Position of internal fan 1
Fig. 4.19: Position of internal fan 2
Related topics
“10.5 Clean/replace internal fan 1”, page 112
“10.6 Clean/replace internal fan 2”, page 116
4.8.3 Internal heat sinks
Fig. 4.20: Rear cover plate
The rear cover plate can be removed.
