5 Planning the installation
Characteristic curves
Installation and Operation Manual for Solar Power Inverter M70A EU V1.1 EN 2020-02-20
32
92%
94%
96%
98%
99%
97%
95%
93%
100%
0 20% 40% 60% 80% 100%
U
AC
= 400 V
AC
800 V
DC
600 V
DC
520 V
DC
AC Output power P/P
n
[%]; P
n
= 125 kW
Efficiency [%]
Fig. 5.29: Eciency characteristic curve
