Delta M70A

73
Installation and Operation Manual for Solar Power Inverter M70A EU V1.1 EN 2020-02-20
7 Installation
Connecting the communication card
...
Data logger
5. Connect the DATA+ wire to terminal 5 and the DATA– wire
to terminal 6.
6. Set the DIP switch for the RS485 termination resistor to
the ON position.
