Delta M70A

7 Installation
Installing the Sub-1G antenna (optional)
Installation and Operation Manual for Solar Power Inverter M70A EU V1.1 EN 2020-02-20
78
3. Rotate the Sub-1G antenna downward.
4. Slide the mounting frame over the Sub-1G antenna upside
down from below.
5. Rotate the mounting frame with the Sub-1G antenna
upward.
