VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
22
5.1.2 List of relevant parameters and addresses for the CMM-EIP01 communication
card applicable to VFD-MS300/MH300:
Object Instance Attributes Keypad number Attributes Description of Function
0x300 0x09
0x00
09-00
RW
VFD-MS300/MH300
Communication Address
0x3D
09-61
RW
CMM-EIP01 Firmware Version
0x3E
09-62
RW
CMM-EIP01 Product Code
0x3F
09-63
RW
CMM-EIP01 Fault
0x4B 09-75
RW
IP Configuration
0 – Static
1 – DHCP
0x4C
09-76
RW
IP Address 1
0x4D
09-77
RW
IP Address 2
0x4E
09-78
RW
IP Address 3
0x4F
09-79
RW
IP Address 4
0x50
09-80
RW
Net Mask 1
0x51
09-81
RW
Net Mask 2
0x52
09-82
RW
Net Mask 3
0x53
09-83
RW
Net Mask 4
0x54
09-84
RW
Gateway 1
0x55
09-85
RW
Gateway 2
0x56
09-86
RW
Gateway 3
0x57
09-87
RW
Gateway 4
0x58
09-88
RW
Password Low (0~255)
0x59
09-89
RW
Passwrod High (0~255)
0x5A 09-90
RW
Return to Factory Setting
0x5B 09-91
RW
CMM-EIP01 Setting
Bit 0: Enable IP Filter
Bit 1: Internet parameter enable
Bit 2: Login password enable
0x5C 09-92
RW
CMM-EIP01 Status
Bit 0: Password enable
