VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
30
5.2.1 IN / OUT settings of register's address (refer to the table below)
The 128-word address of the IN / OUT register has the following setting structure:
Object Instance Attributes CMM-EIP01 Word
IN / OUT
corresponding address
Description
0x04 0x80 0x03
R 0~24
IN 0 – IN 24's
corresponding address
Fixed INPUT address; address
data cannot be changed
R 25~31
IN 25 – IN 31's
corresponding address
Non-fixed INPUT address;
address data can be changed
R 32~63
IN 0~IN 31
Initial setting of return
value
INPUT initial setting value
RW 64~79
OUT0–15's
corresponding address
Fixed OUTPUT address;
address data cannot be
changed
RW 80~95
OUT16-31's
corresponding address
Non-fixed OUTPUT address;
address data can be changed
RW 96~127
IN 0~IN31
Initial setting of return
value
OUTPUT initial setting value
Detailed settings of the IN/OUT register's 128-word address are listed in the following table:
Object Instance Attributes CMM-EIP01 Word
IN / OUT
corresponding address
Description
0x04 0x80 0x03
R 0
IN 0's
corresponding address
Fixed 2100h (Warn / Error)
R 1
IN 1's
corresponding address
Fixed 2101h (Status)
R 2
IN 2's
corresponding address
Fixed 2102h
(Frequency command)
R 3
IN 3's
corresponding address
Fixed 2103h
(Output frequency)
R 4
IN 4's
corresponding address
Fixed 2104h (Output current)
R 5
IN 5's
corresponding address
Fixed 2105h (DC-Bus voltage)
R 6
IN 6's
corresponding address
Fixed 2106h (Output voltage)
R 7
IN 7's
corresponding address
Fixed 2107h (current speed
under multispeed settings)
R 8
IN 8's
corresponding address
Fixed 2108h (Reserved)
R 9
IN 9's
corresponding address
Fixed 2109h (Counter value)
R 10
IN 10's
corresponding address
Fixed 210Ah (Output power
factor angle)
R 11
IN 11's
corresponding address
Fixed 210Bh (Output torque)
R 12
IN 12's
corresponding address
Fixed 210Ch (actual motor
rotational speed)
R 13
IN 13's
corresponding address
Fixed 210Dh (PG feedback
pulse count)
R 14
IN 14's
corresponding address
Fixed 210Eh (PG2 pulse
command count)
R 15
IN 15's
corresponding address
Fixed 210Fh (output power)
