VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
33
5.2.2 IN/OUT buffer address register settings
Currently, 32 sets of IN / OUT buffers are provided for dynamic mapping; the addresses
are organized as follows:
32-word IN/OUT registers have the following setting structure:
Object Instance Attributes CMM-EIP01 Word
IN / OUT
corresponding address
Description
0x04
0x69
0x03
R 0~24
IN0–IN24's
corresponding address
Returns the fixed input
address value
R 16~31
IN16 – IN31's
corresponding address
Returns the dynamic input
address value
0x68
RW 0~15
OUT0–15's
corresponding address
Returns the fixed output
address value
RW 16~31
OUT16-31's
corresponding address
Returns dynamic output
address value
Detailed settings of IN / OUT register's 32-word address are listed in the following table:
Object Instance Attributes CMM-EIP01 Corresponding address Description
0x04
0x69
0x03
R Return value of IN 0 Fixed 2100h (Warn / Error)
R Return value of IN 1 Fixed 2101h (Status)
R Return value of IN 2 Fixed 2102h (Frequency command)
R Return value of IN 3 Fixed 2103h (Output frequency)
R Return value of IN 4 Fixed 2104h (Output current)
R Return value of IN 5 Fixed 2105h (DC-Bus voltage)
R Return value of IN 6 Fixed 2106h (Output voltage)
R Return value of IN 7
Fixed 2107h (current speed under
multispeed settings)
R Return value of IN 8 Fixed 2108h (Reserved)
R Return value of IN 9 Fixed 2109h (Counter value)
R Return value of IN 10 Fixed 210Ah (Output power factor angle)
R Return value of IN 11 Fixed 210Bh (Output torque)
R Return value of IN 12 Fixed 210Ch (actual motor rotational speed)
R Return value of IN 13 Fixed 210Dh (PG feedback pulse count)
R Return value of IN 14 Fixed 210Eh (PG2 pulse command count)
R Return value of IN 15 Fixed 210Fh (output power)
R Return value of IN 16 Fixed 6100h (status word)
R Return value of IN 17 Fixed 6101h (current mode)
R Return value of IN 18 Fixed 6102h (current speed)
R Return value of IN 19 Fixed 6103h (Reserved)
R Return value of IN 20 Fixed 6104h (current position L)
R Return value of IN 21 Fixed 6105h (current position H)
R Return value of IN 22 Fixed 6106h (current torque)
R Return value of IN 23 (Reserved)
R Return value of IN 24 (Reserved)
R Return value of IN 25
Returns the value of dynamic
corresponding address In 25
R Return value of IN 26
Returns the value of dynamic
corresponding address In 26
