VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
34
Object Instance Attributes CMM-EIP01 Corresponding address Description
0x69
R Return value of IN 27
Returns the value of dynamic
corresponding address In 27
R Return value of IN 28
Returns the value of dynamic
corresponding address In 28
R Return value of IN 29
Returns the value of dynamic
corresponding address In 29
R Return value of IN 30
Returns the value of dynamic
corresponding address In 30
R Return value of IN 31
Returns the value of dynamic
corresponding address In 31
0x04
0x68
0x03
RW OUT 0's setting value Set 2000H (control word) =?
RW OUT 1's setting value Set 2001H (Frequency command) =?
RW OUT 2's setting value Set 2002H (EXT) =?
RW OUT 3's setting value Reserved
RW OUT 4's setting value Set 6000H (control word) =?
RW OUT 5's setting value Set 6001H (Control mode) =?
RW OUT 6's setting value Set 6002H (Frequency command) =?
RW OUT 7's setting value Set 6003H (Torque limit) =?
RW OUT 8's setting value Set 6004H (Position command L) =?
RW OUT 9's setting value Set 6005H (Position command H) =?
RW OUT 10's setting value Set 6006H (Torque command) =?
RW OUT 11's setting value Set 6007H (speed limit) =?
RW OUT 12's setting value Reserved
RW OUT 13's setting value Reserved
RW OUT 14's setting value Reserved
RW OUT 15's setting value Reserved
RW OUT 16's setting value Dynamic corresponding address Out 16= ?
RW OUT 17's setting value Dynamic corresponding address Out 17= ?
RW OUT 18's setting value Dynamic corresponding address Out 18= ?
RW OUT 19's setting value Dynamic corresponding address Out 19= ?
RW OUT 20's setting value Dynamic corresponding address Out 20= ?
RW OUT 21's setting value Dynamic corresponding address Out 21= ?
RW OUT 22's setting value Dynamic corresponding address Out 22= ?
RW OUT 23's setting value Dynamic corresponding address Out 23= ?
RW OUT 24's setting value Dynamic corresponding address Out 24= ?
RW OUT 25's setting value Dynamic corresponding address Out 25= ?
RW OUT 26's setting value Dynamic corresponding address Out 26= ?
RW OUT 27's setting value Dynamic corresponding address Out 27= ?
RW OUT 28's setting value Dynamic corresponding address Out 28= ?
RW OUT 29's setting value Dynamic corresponding address Out 29= ?
RW OUT 30's setting value Dynamic corresponding address Out 30= ?
RW OUT 31's setting value Dynamic corresponding address Out 31= ?
