VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
7
Status
code
Status name
Definition
0x15 Too much data
Received data exceeds what is required in executing the
command
0x20 Invalid parameter
Illegal parameter requested. The requested parameter is invalid,
indicating that the parameter does not fit the definition of the
requirement, or the requirement has already been defined in
"Application Object Specification".
0x26 Path Size Invalid
The size of a path transmitting requested service is insufficient for
transmitting to the object by request, or too much routing data is
covered
1.5.4 Error codes for connecting to monitoring service requests
Status
code
Extended
status code
Definition
0x00
－
Service execution successful
0x01 0x0100
Connection is in progress or the connection is re-opened.
The extended status code will be returned when the source is attempting to
establish a connection to the target, but the target has already been
connected.
0x01 0x0103
Does not support the combination of this transmission type and trigger
The target does not support the defined combination of transmission type
and trigger. The router will not terminate the connection, only the target is
required to return this extended status code.
0x01 0x0106
Conflict of right to control
Another connection has taken control and is preventing other connections
from being established. When this device connects in an exclusive manner,
only one connection will be allowed to control this device.
0x01 0x0107
Unable to locate the corresponding target in order to connect.
0x01 0x0108
Illegal network connection parameter
When the target's application program does not support the defined
connection mode or connection class, or if there are too many users, this
extended status code will be returned. Only the target node has to return this
extended status code.
0x01 0x0109
Data exchange zone size settings are invalid
This device does not support the setting of the current data exchange zone;
the setting may be too large or too small.
0x01 0x0111
RPI setting not supported
0x01 0x0113
The number of connections has exceeded the maximum allowed.
The maximum number of connections has been reached; no additional
connections are allowed for this device.
0x01 0x0114
Vendor ID does not match the product code
The product code or vendor ID marked in the electronic key's logic section
does not match the record in the target device.
0x01 0x0115
Product type mismatch
The product type marked in the electronic key's logic section does not match
the record in the target device.
0x01 0x0116
Version mismatch
The primary and secondary revised versions marked in the electronic key's
logic section do not match the records in the target device.
0x01 0x0315
Invalid section exists in the connection path
The section type or section value in the path is invalid. If the device is unable
to interpret the path, it will respond with this extended status code. Causes
of this error include unidentifiable path types, unexpected section types, or
other problems.
