Chapter 4 Parameters|VFD-VL
4-94
It can get RMS value by Pr.08-00=2 (Motor Auto Tuning).
08-09
Angle between Magnetic Pole and PG Origin
Control
mode
FOCPM
Factory setting: 360.0
Settings
0.0~360.0°
This function is used to measure the angle between magnetic pole and PG origin.
08-10
Magnetic Pole Re-orientation
Control
mode
FOCPM
Factory setting: 0
Settings 0 Disable
1 Enable
Please use with Pr.11-00 bit15=1.
This function is used for searching magnetic pole position and only for permanent magnet
motor.
When it doesn’t have origin-adjustment for encoder (Pr.08-09 is 360.0), it can only ensure that
the motor operation efficiency can be up to 86% of the best efficiency. In this situation, when
the operation efficiency needs to be improved, user can re-power on or set Pr.08-10 to 1 to get
the magnetic pole orientation.
