Chapter 4 Parameters|VFD-VL
4-35
01-12
Accel. Time 1
01-14
Accel. Time 2
01-16
Accel. Time 3
01-18
Accel. Time 4
Control
mode
VF VFPG SVC FOCPG FOCPM
Factory setting: 3.00
Settings 0.00~600.00 sec
01-13
Decel. Time 1
01-15
Decel. Time 2
01-17
Decel. Time 3
01-19
Decel. Time 4
Control
mode
VF VFPG SVC FOCPG FOCPM
Factory setting: 2.00
Settings 0.00~600.00 sec
01-20
JOG Acceleration Time
01-21
JOG Deceleration Time
Control
mode
VF VFPG SVC FOCPG FOCPM
Factory setting: 1.00
Settings 0.00~600.00 sec
The Acceleration Time is used to determine the time required for the AC motor drive to ramp
from 0Hz to Maximum Output Frequency (Pr.01-00).
The Deceleration Time is used to determine the time require for the AC motor drive to
decelerate from the Maximum Output Frequency (Pr.01-00) down to 0Hz.
The Acceleration/Deceleration Time 1, 2, 3, 4 are selected according to the Multi-function Input
Terminals settings. The factory settings are acceleration time 1 and deceleration time 1.
The larger against torque and inertia torque of the load and the accel./decel. time setting is
less than the necessary value, it will enable torque limit and stall prevention function. When it
happens, actual accel./decel. time will be longer than the action above.
