Denon AVR-3808CI Service Manual

118
AVR-3808CI / AVR-3808 / AVC-3808
Except for Japan model
FB603-614 nsp CHIP EMIFIL(11A121) +1608
FB701-704 nsp CHIP EMIFIL(11A121) +1608
JK101 00D 205 1362 009 XM/DT BUS CONNECTOR EU,EC
JK102 00D 205 1222 000 RJ-45 JACK(GND)
JK401 00D 205 1333 009 8P MODULAR
JK402 00D 205 1381 006 USB CONNECTOR
JK501-503 00D 204 8719 005 19P HDMI CONNECTOR
JK551 00D 204 8719 005 19P HDMI CONNECTOR
JK701 00D 204 8719 005 19P HDMI CONNECTOR
L401 nsp INDUCTOR 2.2UH(7E06N
L601 nsp INDUCTOR(FLC32C220K)+3216
L602 nsp INDUCTOR6.8uH(7E06N)-1
L802 nsp INDUCTOR(FLC32C220K)+3216
L901 nsp INDUCTOR(FLC32C220K)+3216
RL701 nsp RELAY(UB2-5NUN-L1)
W101 nsp M3 SCREW TERMINAL
W553 nsp M3 SCREW TERMINAL
X101 nsp FCX-03(24.576MHz)
X102 nsp FCX-02(45.1584MHz) EU,EC
X201 nsp FCX-03(20.815MHz)
X251 nsp FCX-03(20.815MHz)
X401 nsp FCX-03(24.576MHz)
X551 nsp FCX-03(28.322MHZ)
X801 nsp FCX-03(28.6363MHz)
X901 nsp XTAL(13.5MHZ) +REF
X902 nsp FCX-03(12MHZ)
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-3808CI Specifications

General

Brand	Denon
Model	AVR-3808CI
Category	Receiver
Language	English
