Denon AVR-3808CI Service Manual

86
AVR-3808CI / AVR-3808 / AVC-3808
SN65LVDS32PW (DI: IC107)
TC74VHCU04F (AV: IC806,807)
CXA1511M (PA: IC802)
SN74LVC139APWR (DI: IC203)
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
1G
1A
1B
1Y0
1Y1
1Y2
1Y3
GND
V
CC
2G
2A
2B
2Y0
2Y1
2Y2
2Y3
FUNCTION TABLE
(each decoder/demultiplexer)
INPUTS
OUTPUTS
G
SELECT
OUTPUTS
G
B A Y3 Y2 Y1 Y0
L L L H H H L
L L HHHLH
L H LHLHH
L H HLHHH
H X X H H H H
