Denon AVR-3808CI Service Manual

165
AVR-3808CI / AVR-3808 / AVC-3808
AVC-3808 : Japan model
1U-3817J DIGITAL POWER P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC802 00D 263 1280 006 SI-8008HFE
IC803 00D 263 1186 003 SI-8033S(LF1101)
IC804 00D 263 1280 006 SI-8008HFE
IC805 00D GEN 8374 RADITOR SUB ASSY SI-8001FFE(LF1113A)
IC807 00D 263 1242 918 NJM2831F06
z IC809 00D 268 0073 905 ICP-N15T
IC811 00D 263 1035 002 PQ30RV11
TR801 00D 272 0161 900 2SB1412TL(PQR) +C
TR802 00D 269 0048 904 DTC143EK-T96 +C
TR803 00D 273 0464 901 KTC3875S-GR-RTK/P
TR804 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR806 00D 273 0464 901 KTC3875S-GR-RTK/P
TR808-810 00D 273 0464 901 KTC3875S-GR-RTK/P
TR811-813 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR815 00D 271 0313 904 KTA1281-Y-AT/P
TR816 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR820 00D 273 0464 901 KTC3875S-GR-RTK/P
D802,803 00D 276 0704 916 1SR35-400A(T82)
D804 00D 276 0847 909 RSX101M-30
D805 00D 276 0854 905 RSX501L-20
D806 00D 276 0401 905 1SS133T77 (TAPE)
D809-811 00D 276 0401 905 1SS133T77 (TAPE)
D813 00D 276 0704 916 1SR35-400A(T82)
D818 00D 276 0305 001 S4VB20
D819-822 00D 276 0850 705 RSX1001T3
D824 00D 276 0704 916 1SR35-400A(T82)
ZD805 00D 276 0464 900 HZS7A-1TD
ZD806-808 00D 276 0461 903 HZS6A-1TD
ZD810 00D 276 0466 908 HZS7C-1TD
ZD825 00D 276 0477 900 HZS16-1 TD(TAPE)
RESISTORS GROUP
R801 00D 244 2052 960 RS14B3A221JNBST(S)
R803 00D 247 0047 947 RM73B--472DT
R804 00D 247 0045 965 RM73B--821DT
R808 00D 247 0047 947 RM73B--472DT
R809 00D 247 0047 934 RM73B--432DT
R824 00D 247 0047 992 RM73B--752DT
R825 00D 247 0045 965 RM73B--821DT
R826 00D 247 0047 992 RM73B--752DT
R827 00D 247 0045 965 RM73B--821DT
R828 00D 247 0046 948 RM73B--182DT
R830 00D 247 0044 982 RM73B--391DT
CAPACITORS GROUP
C803-806 nsp CK73B1H102KT +1608
C807 00D 255 1279 919 CQ93M1H473JT(B)
C811,812 00D 254 4651 913 CE04W0J102MT H15(KY)
C816 00D 254 4193 905 CE04W1C100MT (SRA)
C817 00D 254 4524 985 CE04W1H100MT SMG/RE3
C819-821 nsp CK73B1E104KT +1608
C822-824 00D 254 4653 911 CE04W1V271MT H20D(KY
C825 00D 255 1279 951 CQ93M1H104JT(B)
C826 00D 254 4801 705 CE04W1V103MC(SMQ)
C828 00D 254 4651 913 CE04W0J102MT H15(KY)
C829 nsp CK73B1E104KT +1608
C830 00D 254 4653 911 CE04W1V271MT H20D(KY
C831 00D 254 4524 943 CE04W1H010MT SMG/RE3
