Denon AVR-3808CI - 1 U-3806 P.AMP P.W.B. Unit ASSY (EU,EC,EUT,E1 C Model); 1 U-3806 A P.AMP P.W.B. Unit ASSY (BKE2,SRE2,E2 A Model) - Parts List

124
AVR-3808CI / AVR-3808 / AVC-3808
Except for Japan model
1U-3806 P.AMP P.W.B. UNIT ASS'Y (EU,EC,EUT,E1C model)
1U-3806A P.AMP P.W.B. UNIT ASS'Y (BKE2,SRE2,E2A model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC801 00D 262 3676 903 TC74VHCT08AF(E,K,F)
IC802 00D 262 2580 906 CXA1511M +C
TR101 00D 271 0301 903 KTA1268-BL-AT/P
TR102-108 00D 273 0458 904 KTC3200-BL-AT/P
TR109-112 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR114,115 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR121 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR123 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR125 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR127 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR131 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR133 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR147 00D 271 0301 903 KTA1268-BL-AT/P
TR149 00D 273 0464 901 KTC3875S-GR-RTK/P
TR152 00D 273 0464 901 KTC3875S-GR-RTK/P
TR153 00D 271 0312 905 KTA1504S-GR-RTK/P
TR155 00D 273 0464 901 KTC3875S-GR-RTK/P
TR157 00D 273 0464 901 KTC3875S-GR-RTK/P
TR158 00D 271 0312 905 KTA1504S-GR-RTK/P
TR161,162 00D 273 0464 901 KTC3875S-GR-RTK/P
TR165 00D 271 0312 905 KTA1504S-GR-RTK/P
TR166 00D 273 0464 901 KTC3875S-GR-RTK/P
TR705-728 00D 273 0460 905 KTC2875-B-RTK/P
TR801 00D 273 0464 901 KTC3875S-GR-RTK/P
TR802,803 00D 269 0191 903 KRA104S-RTK/P (47K-47K)
TR804 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR805 00D 271 0326 904 2SA1954(B)-TE85L
TR806 00D 271 0316 901 KTA1042D-Y-RTF/P
TR807 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR808 00D 271 0316 901 KTA1042D-Y-RTF/P
TR809 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
D101-121 00D 276 0401 905 1SS133T77 (TAPE)
D147 00D 276 0683 930 UDZS5.1B-TE17 +C
D151-154 00D 276 0338 007 S4VB20F
D166-169 00D 276 0401 905 1SS133T77 (TAPE)
D171,172 00D 276 0401 905 1SS133T77 (TAPE)
D801,802 00D 276 0794 900 KDS160-RTK/P
D803-805 00D 276 0833 900 ESD PROTECTOR(6802)
D806 00D 276 0794 900 KDS160-RTK/P
ZD101-114 00D 276 0643 970 MTZJ4.7A T77
ZD801 00D 276 0798 906 UDZS6.2B-TE17
ZD802,803 00D 276 0683 998 UDZS16B-TE17 +C
RESISTORS GROUP
R108-121 00D 244 2050 904 RS14B3A220JNBST(S)
R122-149 00D 244 2671 956 RS14B3DR47JNBST(S)
R171 00D 244 2051 961 RS14B3A101JNBST(S)
R193 00D 241 2387 940 RD14B2E4R7JNBST
R215,216 00D 243 2039 032 RW99=3H0R1K
R217-223 00D 244 2682 945 RS14B3D2R2JNBST(S)
R224-230 00D 244 2671 901 RS14B3D100JNBST(S)
R233-235 00D 244 2055 996 RS14B3A122JNBST(S)
R236-239 00D 244 2052 960 RS14B3A221JNBST(S)
VR101-107 00D 211 6158 909 V06PB331T BKE2,SRE2,E2A
