Denon AVR-3808CI Service Manual

92
AVR-3808CI / AVR-3808 / AVC-3808
2. TRNSISTOR
MP15P (PA: TR202,204,206,208,210,212,214) MN15N (PA: TR201,203,205,207,209,211,213)
3. OTHERS
GP1UM271XK (Remote Control Sensor) (FR: IC101)
4. OPTICAL
TORX142 (AV: IC801,802,803) TOTX142 (AV: IC804,805) GP1FM313RZ (AV: IC701)
5. LED
SML1216W (LED) (FR: LD301)
ES CDB
B
D
C
E
S
R:70ohm Typ.
RE:0.22ohm Typ.
BDC S E
B
D
C
E
S
R:70ohm Typ.
RE:0.22ohm Typ.
FRONT
VIEW
FRONT
VIEW
GND
Vcc
Vout
GND
VOUT
Vcc
Head
Amp
Limiter
Amp
BPF
Detector &
Comparator
Integrator
Hysteresis
Comparator
RED GREEN
