Denon AVR-3808CI Service Manual

119
AVR-3808CI / AVR-3808 / AVC-3808
Except for Japan model
1U-3800E A.VIDEO P.W.B. UNIT ASS'Y (EU,EC,BKE2,SRE2,E2A,EUT,E1C model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401-410 00D 263 1082 903 TK15420MTL +C
IC411,412 00D 262 3445 901 TC4051BFT
IC413,414 00D 262 3447 909 TC4053BFT
IC415,416 00D 262 3446 900 TC4052BFT
IC417,418 00D 262 3445 901 TC4051BFT
IC419 00D 262 3446 900 TC4052BFT
IC420,421 00D 262 3445 901 TC4051BFT
IC505,506 00D 263 1197 908 BU4094BCFV-E2
IC508 00D 263 1197 908 BU4094BCFV-E2
IC510 00D 262 3717 901 LC74781M
IC512 00D 262 3447 909 TC4053BFT
IC601 00D 262 3551 002 NJW1321FP1
IC602,603 00D 263 1225 906 NJM2581M-TE1
IC701 00D 269 0240 003 GP1FMV31RK0F
IC702 00D 263 0615 902 BA15218F-DXE2 +C
IC703 00D 263 1273 903 NJM2566AV
IC801-803 00D 269 0241 002 TORX142L(F)
IC804,805 00D 269 0242 001 TOTX142L(F)
IC806,807 00D 262 3077 900 TC74VHCU04FT +REF
IC808,809 00D 262 3412 905 TC74VHC14FT
IC810,811 00D 262 2944 908 SN74HC151APW-EL2 +REF
IC812 00D 263 1197 908 BU4094BCFV-E2
IC813 00D 262 2944 908 SN74HC151APW-EL2 +REF
IC815 00D 263 1197 908 BU4094BCFV-E2
IC902 00D 262 3571 901 HIN202EIBNZ-T
TR401-403 00D 271 0312 905 KTA1504S-GR-RTK/P
TR405-407 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR409-411 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR501 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR502 00D 271 0312 905 KTA1504S-GR-RTK/P
TR503,504 00D 273 0464 901 KTC3875S-GR-RTK/P
TR603 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR604 00D 269 0144 905 DTC114YK-T146 +C
TR605 00D 271 0312 905 KTA1504S-GR-RTK/P
TR771 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
D401-403 00D 276 0794 900 KDS160-RTK/P
D405-407 00D 276 0794 900 KDS160-RTK/P
D501,502 00D 276 0794 900 KDS160-RTK/P
D608 00D 276 0773 905 RB501V-40 +2125
D609,610 00D 276 0794 900 KDS160-RTK/P
D801-803 00D 276 0738 908 KDS226-RTK/P (A-K)
D901,902 00D 276 0833 900 ESD PROTECTOR(6802)
ZD701-703 00D 276 0683 930 UDZS5.1B-TE17 +C
ZD704,705 00D 276 0829 901 NSAD500F-T1B
RESISTORS GROUP
R401-412 00D 247 2019 928 RM73B--750FT
R420-425 00D 247 2045 918 RM73B--151FT_1608
R429-434 00D 247 2045 918 RM73B--151FT_1608
R447-454 00D 247 2045 918 RM73B--151FT_1608
R601-624 00D 247 2045 918 RM73B--151FT_1608
R675 00D 247 2045 921 RM73B--161FT_1608
R676 00D 247 2045 918 RM73B--151FT_1608
R677 00D 247 2045 921 RM73B--161FT_1608
R678 00D 247 2045 918 RM73B--151FT_1608
R679 00D 247 2045 921 RM73B--161FT_1608
R680 00D 247 2045 918 RM73B--151FT_1608
R681 00D 247 2045 921 RM73B--161FT_1608
R682 00D 247 2045 918 RM73B--151FT_1608
