Denon AVR-3808CI

171
AVR-3808CI / AVR-3808 / AVC-3808
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ 本表に"nsp" と記載されている基板 ASS’Y は供給できません。基板 ASS’Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replace-
ment parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
EU : U.S.A. model EC : Canada model SRE2 : Europe model(Silver) BKE2 : Europe model(Black)
E2A : Asia model E1C : China model EUT : Taiwan R.O.C. model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
1 00D 1U- 3799 E DIGITAL UNIT ASSY 1U-3799E : EU,EC 1 *
1 00D 1U- 3799 F DIGITAL UNIT ASSY 1U-3799F : BKE2,SRE2,E2A,E1C 1 *
1 00D 1U- 3799 G DIGITAL UNIT ASSY 1U-3799G : EUT 1 *
1 00D 1U- 3799 J DIGITAL UNIT ASSY 1U-3799J : JP 1 *
2 nsp A.VIDEO UNIT ASSY
1U-3800E :
EU,EC,BKE2,SRE2,E2A,EUT,E1C
1*
2 nsp A.VIDEO UNIT ASSY 1U-3800J : JP 1 *
2-1 A.VIDEO UNIT 1
2-2 VIDEO CONNECT UNIT 1
2-3 FRONT IN UNIT 1
2-4 MIC UNIT 1
2-5 USB UNIT 1
2-6 DIGITAL IN UNIT 1
2-7 232C UNIT 1
2-8 BKT1 UNIT 1
2-9 BKT2 UNIT 1
3 nsp P.AMP UNIT ASSY 1U-3806 : EU,EC,EUT,E1C 1 *
3 nsp P.AMP UNIT ASSY 1U-3806A : BKE2,SRE2,E2A 1 *
3 nsp P.AMP UNIT ASSY 1U-3806D : JP 1 *
3-1 P.AMP UNIT 1
3-2 IPOD UNIT 1
3-3 AUDIO CONNECT UNIT 1
3-4 LR CONNECT UNIT 1
4 nsp P.SUPPLY UNIT ASSY 1U-3802E : EU,EC 1 *
4 nsp P.SUPPLY UNIT ASSY 1U-3802F : BKE2,SRE2,E2A 1 *
4 nsp P.SUPPLY UNIT ASSY 1U-3802G : EUT 1 *
4 nsp P.SUPPLY UNIT ASSY 1U-3802H : E1C 1 *
4 nsp P.SUPPLY UNIT ASSY 1U-3802J : JP 1 *
4-1 PRIMARY UNIT 1
4-2 P.SUPPLY-1 UNIT 1
4-3 VOL_AMP UNIT 1
4-4 SIDE CONNECT UNIT 1
4-5 PRIMARY UNIT BKE2,SRE2,E2A 1
4-6 AMP CONNECT UNIT 1
5 nsp FRONT UNIT ASSY 1U-3845 : EU,EC,EUT 1 *
5 nsp FRONT UNIT ASSY 1U-3845A : BKE2,SRE2,E2A 1 *
5 nsp FRONT UNIT ASSY 1U-3845D : JP 1 *
5 nsp FRONT UNIT ASSY 1U-3845H : E1C 1 *
5-1 P.SUPPLY-2 UNIT 1
5-2 FLD UNIT 1
5-3 FUNC UNIT 1
5-4 H/P UNIT 1
5-5 P.SW UNIT 1
