172
AVR-3808CI / AVR-3808 / AVC-3808
5-6 TOP CONNECT UNIT 1
5-7 FUNC CONNECT UNIT 1
5-8 H/P CONNECT UNIT 1
6 nsp AUDIO/CPU UNIT ASSY 1U-3804E : EU,EC 1 *
6 nsp AUDIO/CPU UNIT ASSY 1U-3804F : BKE2,SRE2 1 *
6 nsp AUDIO/CPU UNIT ASSY 1U-3804G : E2A,EUT 1 *
6 nsp AUDIO/CPU UNIT ASSY 1U-3804H : E1C 1 *
6 nsp AUDIO/CPU UNIT ASSY 1U-3804J : JP 1 *
6-1 AUDIO UNIT 1
6-2 MAIN CPU UNIT 1
7 nsp DIGITAL POWER UNIT ASSY 1U-3817E : EU,EC,EUT 1 *
7 nsp DIGITAL POWER UNIT ASSY 1U-3817F : BKE2,SRE2,E2A,E1C 1 *
7 nsp DIGITAL POWER UNIT ASSY 1U-3817J : JP 1 *
11 nsp MAIN CHASSIS 1
12 nsp CENTER CHASSIS 1
13 nsp BOTTOM PLATE 1
14 nsp FOOT 4
15 nsp RUBBER PAD 4
16 nsp RADIATOR 1
17 nsp CU PLATE 1
18 00D 278 0017 007 MN15N/MP15P 7
18-1 nsp MN15N TR201,203,205,207,209,211,213
18-2 nsp MP15P TR202,204,206,208,210,212,214
19 nsp PWB BRACKET 2
20 nsp RADIATOR BRACKET (L) 1
21 nsp RADIATOR BRACKET (R) 1
23 nsp CARD SPACER (L=8) MPS-08-0 2
24 nsp CARD SPACER(L=10) MPS-10-0 2
25 nsp P.W.B.HOLDER (H=8) KGLS-8RT:Fix CPU POWER UNIT 2
26 00D 105 1692 000 BACK PANEL EU,EC 1 *
26 00D 105 1692 013 BACK PANEL BKE2,SRE2,E2A 1 *
26 00D 105 1692 039 BACK PANEL E1C 1 *
26 00D 105 1692 042 BACK PANEL EUT 1 *
26 00D 105 1692 026 BACK PANEL JP 1 *
27 nsp HOLDER (A) KGLS-10S:Fix LR CONNECT UNIT 1
28 00D 216 0124 002 AM FM TUNER(E3) EU,EC 1
28 00D 216 0125 001 AM FM TUNER(E2) BKE2,SRE2,E2A,EUT 1
31 nsp RUBBER FOAM 2
32 00D 205 1116 006 TERMINAL ASS 1
z 33 00D 203 3996 008 AC INLET (2P) 1
★34
nsp 2P VA CORD AC INLET to CX201 1
35 nsp P.W.B.HOLDER (H=6) KGLS-6RT:Fix SIDE CONNECT UNIT 1
36 nsp P.W.B.HOLDER (H=10) KGLS-10RT:Fix MAIN CPU UNIT 1
37 nsp CARD SPACER (H=10) KGPS-10RF:Fix MAIN CPU UNIT 1
★38
nsp WIRE CLAMPER 16
z 44 00D 233 0737 009 MAIN TRANS(38CIE3) EU,EC,EUT 1 *
z 44 00D 233 6617 000 MAIN TRANS(38E2) BKE2,SRE2,E2A 1 *
z 44 00D 233 6618 009 MAIN TRANS(38E1C) E1C 1 *
z 44 00D 233 0727 006 MAIN TRANS(38CIJP) JP 1 *
47 nsp LABEL (TRANS) 1
48 nsp RUBBER SHEET 1
49 00D GEN 8568 TOP COVER SUB ASSY EU,EC,BKE2 : 102 0704 000 1
Ref. No. Part No. Part Name Remarks Q'ty New
