Denon AVR-3808CI Service Manual

159
AVR-3808CI / AVR-3808 / AVC-3808
AVC-3808 : Japan model
1U-3845D FRONT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 499 0318 002 GP1UM271XKVF
z IC102 00D 268 0073 905 ICP-N15T
IC601 00D 263 1274 009 NJM2396F12
IC602 00D 263 1100 005 KIA7805API-U/P
IC603 00D 279 0034 067 PTH9M04BB222TS2F333
IC608 00D 263 1163 000 KIA78R09PI-U/P
IC609 00D 263 1092 003 BA05T
IC610 00D 263 0554 005 NJM7905FA
TR101 00D 269 0191 903 KRA104S-RTK/P (47K-47K)
TR102 00D 274 0212 907 2SD1782KT146
TR103 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR106 00D 273 0494 900 KTC2022D-Y-RTF/P
TR112,113 00D 274 0212 907 2SD1782KT146
TR301 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR302,303 00D 271 0312 905 KTA1504S-GR-RTK/P
TR304 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR371-373 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR601 00D 273 0468 907 KTC3199-GR-AT/P
TR602 00D 271 0311 906 KTA1267-GR-AT/P
TR603 00D 274 0198 005 KTD998-O-U/P
TR604 00D 272 0158 007 KTB778-O-U/P
TR605 00D 273 0468 907 KTC3199-GR-AT/P
TR606 00D 271 0311 906 KTA1267-GR-AT/P
TR607 00D 272 0158 007 KTB778-O-U/P
TR608 00D 274 0198 005 KTD998-O-U/P
TR609 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR610 00D 271 0313 904 KTA1281-Y-AT/P
TR615 00D 273 0464 901 KTC3875S-GR-RTK/P
TR626 00D 271 0313 904 KTA1281-Y-AT/P
TR627 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR628 00D 273 0469 906 KTC3209-Y-AT/P
TR629 00D 271 0311 906 KTA1267-GR-AT/P
TR630 00D 272 0158 007 KTB778-O-U/P
TR631 00D 274 0198 005 KTD998-O-U/P
TR632 00D 269 0206 908 KRC102M-AT/P (10K-10K)
TR633 00D 271 0312 905 KTA1504S-GR-RTK/P
D101 00D 276 0704 903 1SR35-400A(T93X)
D602-606 00D 276 0401 905 1SS133T77 (TAPE)
D620 00D 276 0401 905 1SS133T77 (TAPE)
D623,624 00D 276 0723 900 RB721Q-40
ZD101,102 00D 276 0480 900 HZS22-1TD
ZD103 00D 276 0636 903 MTZJ8.2BT77
ZD601,602 00D 276 0468 906 HZS9B-1TD
ZD603,604 00D 276 0475 902 HZS12C-1TD
ZD605 00D 276 0471 906 HZS11B-1TD
ZD609 00D 276 0465 912 HZS7B-2TD
ZD610,611 00D 276 0471 906 HZS11B-1TD
ZD612,613 00D 276 0475 902 HZS12C-1TD
ZD615 00D 276 0476 901 HZS15-1 TD(TAPE)
ZD616 00D 276 0465 912 HZS7B-2TD
LD301 00D 393 9671 002 SMLU12416W-S
LD371-373 00D 393 9662 901 SEL1410ETP2(D2/D3)
FL101 00D 393 8094 004 FLD(19-BT-08GINK)
RESISTORS GROUP
R146 00D 244 2043 937 RS14B3A100JNBST(S)
R149 00D 244 2043 937 RS14B3A100JNBST(S)
