Denon AVR-3808CI Service Manual

156
AVR-3808CI / AVR-3808 / AVC-3808
AVC-3808 : Japan model
1U-3802J P.SUPPLY P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
TR401,402 00D 273 0468 907 KTC3199-GR-AT/P
TR803 00D 271 0301 903 KTA1268-BL-AT/P
TR805-811 00D 271 0301 903 KTA1268-BL-AT/P
TR813-816 00D 271 0301 903 KTA1268-BL-AT/P
TR817-819 00D 273 0471 907 KTC3206-Y-AT/P
TR821-824 00D 273 0471 907 KTC3206-Y-AT/P
TR825-827 00D 271 0314 903 KTA1024-Y-AT/P
TR829-832 00D 271 0314 903 KTA1024-Y-AT/P
TR833-835 00D 273 0471 907 KTC3206-Y-AT/P
TR837-840 00D 273 0471 907 KTC3206-Y-AT/P
TR901,902 00D 271 0301 903 KTA1268-BL-AT/P
D401 00D 276 0704 903 1SR35-400A(T93X)
D403-410 00D 276 0704 903 1SR35-400A(T93X)
D411,412 00D 276 0401 905 1SS133T77 (TAPE)
D413-415 00D 276 0704 903 1SR35-400A(T93X)
D417 00D 276 0305 001 S4VB20
D501 00D 276 0305 001 S4VB20
D504 00D 276 0305 001 S4VB20
D505,506 00D 276 0704 903 1SR35-400A(T93X)
D801-803 00D 276 0401 905 1SS133T77 (TAPE)
D805-811 00D 276 0401 905 1SS133T77 (TAPE)
D813-819 00D 276 0401 905 1SS133T77 (TAPE)
D821-826 00D 276 0401 905 1SS133T77 (TAPE)
RESISTORS GROUP
R404 00D 244 2050 904 RS14B3A220JNBST(S)
R405 00D 244 2064 974 RS14B3A330JNBST(S)
R825-827 00D 241 2379 987 RD14B2E102JNBST
R829-832 00D 241 2379 987 RD14B2E102JNBST
R849-851 00D 241 2379 987 RD14B2E102JNBST
R853-856 00D 241 2379 987 RD14B2E102JNBST
R865-867 00D 244 2671 914 RS14B3D153JNBST(S)
R869-872 00D 244 2671 914 RS14B3D153JNBST(S)
R873-875 00D 241 2378 946 RD14B2E271JNBST
R877-883 00D 241 2378 946 RD14B2E271JNBST
R885-891 00D 241 2378 946 RD14B2E271JNBST
R893-896 00D 241 2378 946 RD14B2E271JNBST
CAPACITORS GROUP
C402 00D 254 4524 943 CE04W1H010MT SMG/RE3
C403 00D 254 4442 708 CE04W1C682MC (SMG)
C405 00D 254 4524 943 CE04W1H010MT SMG/RE3
C407 00D 255 1279 951 CQ93M1H104JT(B)
C408,409 00D 253 8022 707 CK45F2EAC103MC
C410 00D 255 1279 951 CQ93M1H104JT(B)
C411 00D 254 4523 724 CE04W1V472MC SMG/RE3
C412 00D 255 1279 951 CQ93M1H104JT(B)
C501 00D 256 1042 903 CF93A2E104KT
C502,503 00D 255 1279 951 CQ93M1H104JT(B)
C504,505 00D 254 6258 000 CE68W1V822M
C513-515 00D 255 1279 951 CQ93M1H104JT(B)
C516,517 00D 254 4428 706 CE04W1V222MC (SMG)
C518,519 00D 254 4761 706 CE04W1C153MC(SMQ)
C801,802 00D 254 4583 942 CE04W1H100MT(ROB)
C803 00D 254 4524 985 CE04W1H100MT SMG/RE3
C804 00D 254 4583 942 CE04W1H100MT(ROB)
C805-808 00D 254 4524 985 CE04W1H100MT SMG/RE3
C809,810 00D 255 4252 959 CQ93P2A221JT(NH2)
C811 00D 255 1273 944 CQ93M1H221KT(B)
C813-816 00D 255 1273 944 CQ93M1H221KT(B)
