AVR-3808CI / AVR-3808 / AVC-3808
PACKING VIEW
PARTS LIST OF PACKING & ACCESSORIES
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
EU : U.S.A. model EC : Canada model SRE2 : Europe model(Silver) BKE2 : Europe model(Black)
E2A : Asia model E1C : China model EUT : Taiwan R.O.C. model JP : Japan model
Ref. No. Part No. Part Name Remarks
Q't
y
New
201 nsp CABINET SHEET 1
202 00D 503 1544 006 CUSHION ASSY 1
203 nsp PAD 1
204 nsp SPACER 2
205 00D 501 2364 027 CARTON CASE EU,EC 1 *
205 00D 501 2364 030 CARTON CASE BKE2,SRE2,E2A,EUT 1 *
205 00D 501 2364 056 CARTON CASE E1C 1 *
205 00D 501 2364 069 CARTON CASE JP 1 *
206 nsp CONT.CARD(L) 1
207 nsp BAR CODE LABEL ASSY 1
208 nsp P4S LABEL(CARTON) 2
209 nsp COLOR LABEL SRE2 1
209 nsp COLOR LABEL E2A,EUT,E1C 1
210 nsp GUARANTEE CARD (S) JP 1
★211
nsp CARTON LABEL(C) E1C 1
★212
nsp RECYCLE MARK CARTON E1C 1
★213
nsp DATE LABEL E1C 1
★214
nsp CARTON LABEL(T) EUT 1
★215
nsp CARTON LABEL SUB ASS EUT 1
★216
nsp CARTON LABEL SUB ASS EUT 1
202
202
201
207
206
210
208
208
206
230220
231 232
205
204
203
235
234
233
209
209
