AVR-3808CI / AVR-3808 / AVC-3808
WIRES
501 00D 009 0296 002 15P FFC(1.25) MAIN CPU-CX150 to TUNER PACK 1
502 00D 009 0295 032 25P FFC(1.0) MAIN CPU-CX251 to FLD-CY251 1
503 00D 009 0295 016 27P FFC(1.0)
MAIN CPU-CX271 to FRONT IN-
CY271
1
504 00D 009 0295 029 17P FFC(1.0) DIGITAL IN-CX171 to DIGITAL-CY171 1
505 nsp 2P VA-VA CON.CORD PRIMARY-CX022 to P.SW-CY022 1
506 nsp 12P ZH-ZH CON.CORD
SIDE CONNECT-CX124
to DIGITAL-CY124
1
507 nsp 13P ZH-ZH CON.CORD MAIN CPU-CX136 to DIGITAL-CY136 1
509 nsp 12P-4P/8P PH-PH CORD
DIGITAL PWR-CX121
to DIGITAL CY821/CY421
1
512 nsp 7P ZH-ZH CON.CORD CX974 to CY974 1
513 nsp 5P PH-PH CON.CORD USB-CX053 to DIGITAL-CY053 1
Ref. No. Part No. Part Name Remarks Q'ty New
