Denon AVR-3808CI Service Manual

66
AVR-3808CI / AVR-3808 / AVC-3808
M3087BFLBGP Terminal Function
Pin PinName Symbol I/O Type Det
Op
(Int.)
Op
(Ext.)
Res STBY stop Function
1 P96/TXD4 (HDRADIOMOHI) O C - - - Z O/L O/L Notused(HDRADIOcontrol)
2 P95/CLK4 XMANTREV I - E ↓ &L - Eu Z O/L O/L Notused(XMRADIOcontrolpin,ANTENNAnormal:L)
3P94/CTS4 GUIRST O C - - Ed Z O/L O/L GUIcontrolpin
4P93/CTS3 GUIACK I - E ↓ &L - Ed Z O/L O/L GUIcontrolpin
5 P92/TXD3 (SIRIUSMO) O C - - Z O/L O/L Notused(SIRIUScontrol)
6 P91/RXD3 (SIRIUSMI) O(I) - - - - Z O/L O/L Notused(SIRIUScontrol)
7 P90/CLK3 USBSEL O C - - Ed Z O/L O/L USBselectcontrol(FRONT="L",BACK="H")
8 P146/INT8 REMOTEDET I - E ↓ &H - - Z O/L O/L ROOMTOROOMSignaldetectpin(Detected:H)
9 P145/INT7 GUIREQ O C - - Ed Z O/L O/L GUIcontrolpin
10 P144/INT6 (HDMICECIN) I - E ↓ &L - Eu Z I O/L Notused
11 P143 (HDMICECOUT) O C - - - Z O/L O/L Notused
12 P142 CPU/EPOWER O C - - Ed Z O/L O/L
MAINCPUPOWERcontrolpin(POWERON:H)
(ETHER=ONorCECON(STANDBY:H))
13 P141 SCPUPOWER O C - - Ed Z O/L O/L SUBCPUPOWERON/OFFswitcing(H:ON)
14 P140 232CPOWER O C - - Ed Z O/H O/L 232CPOWERcontrolpin
15 BYTE BYTE - - - - - - - - GND(Ext.databusbitwidthswitching,16bit:L)
16 CNVss CNVSS I - - - Ed Z I I
Single-chip/Micro-processormodeswitching(Normal
single-chip:L,Rewritebootprogramstart:Hinputset)
17 P87/XCIN POWER O C - - Ed Z O/L O/L MAINPOWERrelaycontroloutput(ON:H)
18 P86/XCOUT HDPOWER O C - - Ed Z O/L O/L Notused(HDRADIOPOWERcontrolpin)
19 RESET RESET I- Lv -EuLI I Resetinput(reset:L)
20 XOUT X2 O - - - - - O/L O/L Clockoutput
21 VSS VSS - - - - - - - - GND
22 XIN X1 I - - - - - I I Clockinput
23 VCC VCC - - - - - - - - +5V
24 P85/NMI NMI I- - - --- - Notused(FixedtoH)
25 P84/INT2 B.DOWN I-E↓&L-EuZI I Powerdowndetect(Powerdown:L)
26 P83/INT1 POWERKEY I-E↓&L-Eu I O/L InterruptportforWAITmodecancel
27 P82/INT0 REMOCON I - E ↑ &L - Ed Z I I Remotecontrolsignalinput
28 P81 REMOTEPOWER O C - - Ed Z O/L O/L REMOTEPOWERcontrolpin(ON:H)
29 P80/RXD5 iPodRXDMIIO I - - - - Z I O/L IPODcomm.controlpin
30 P77/CLK5 iPodDOCKDET I - - - Eu Z O/L O/L
MINIJACKconnecteddetectionpinforDOCKconnection
(connected:L)
31 P76/TXD5 iPodTXDMOII O C - - - Z O/L O/L IPODcomm.controlpin
32 P75/ISRXD1(UART) USER1LED O C - - Ed Z O/L O/L USER1LEDcontrolpin(ON:H)
33 P74/ISCLK1 USER2LED O C - - Ed Z O/L O/L USER2LEDcontrolpin(ON:H)
34 P73/ISTXD1(UART) USER3LED O C - - Ed Z O/L O/L USER3LEDcontrolpin(ON:H)
35 P72/CLK2 GUICLK O C - - Ed Z O/L O/L GUIcontrolpin
36 P71/RXD2 GUIRX I - - - - Z I O/L GUIcontrolpin
37 P70/TXD2 GUITX O N - - Eu Z O/L O/L GUIcontrolpin
38 P67/TXD1 TXDMO232I O C - - - Z O/L O/L Datatransferoutputtooutside(AMX)
39 VCC VCC - - - - - - - - +5V
40 P66/RXD1 RXDMI232O I - - - Ed Z I O/L Datareceiveinputfromoutside(AMX)
41 VSS VSS - - - - - - - - GND
42 P65/CLK1(SCLK) SCLK O C - - Ed Z O/L O/L Foremulator
43 P64/CTS1(BUSY) BUSY O C - - - Z O/L O/L Foremulator
44 P63/TXD0 ETXDMOEI O C - - - Z O/L O/L ETHERNETcomm.controlpin
45 P62/RXD0 ERXDMIEO I - - - Ed Z I O/L ETHERNETcomm.controlpin
46 P61/CLK0 ERESET O C - - Ed Z O/L O/L ETHERNETcomm.controlpin
47 P60/CTS0 EPOWER O C - - Ed Z O/L O/L ETHERNETPOWERON/OFFswitching(H:ON)
48 P137 ESPICS O C - - - Z O/L O/L ETHERNETcomm.controlpin
49 P136/ISCLK2(SPI) CLKMO O C - - Ed Z O/L O/L MAIN-SUBμcomcomm.controlpin
50 P135/ISRXD2(SPI) SOMI I - - - - Z I O/L MAIN-SUBμcomcomm.controlpin
51 P134/ISTXD2(SPI) MOSI O C - - Ed Z O/L O/L MAIN-SUBμcomcomm.controlpin
52 P57 TRIGGER1 O C - - Ed Z O/L O/L TRIGGEROUT1controlpin
53 P56 TRIGGER2 O C - - Ed Z O/L O/L TRIGGEROUT2controlpin
54 P55/EPM FRASHEPM OC - -EuZO/LO/L Rewritebootprogramstart:Linputset
55 P54 TRIGGERPROTECT I - E ↓ &L - Eu Z I O/L TRIGGERPROTECTIONdetectport
56 P133 H/PDET I - - - Eu Z O/L O/L HEADPHONEdetectinput(Detected:H)
57 VSS VSS - - - - - - - - GND
58 P132 MICDET I - Lv - Eu Z O/L O/L Microphonedetectinput(Detected:H)
59 VCC VCC - - - - - - - - +5V
60 P131 FLRST O C - - Ed Z O/L O/L FLDRIVERcontrolpin
61 P130 USBEN O C - - - Z O/L O/L USBSELECTpin(Normal:H,USBSELECTswitching:L)
62 P53 FLCE1 O C - - - Z O/L O/L FLDRIVERcontrolpin
