Denon AVR-3808CI Service Manual

162
AVR-3808CI / AVR-3808 / AVC-3808
AVC-3808 : Japan model
1U-3804J AUDIO/CPU P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101-112 00D 263 0896 909 NJM2068MD-TE1 +C
IC301 00D 262 3739 002 APPA300
IC451 00D 263 0896 909 NJM2068MD-TE1 +C
IC501 00D 263 0896 909 NJM2068MD-TE1 +C
IC701 00D GEN 8560 C MAIN CPU SUB ASSY M3087BFLBGP
IC801,802 00D 262 3410 907 TC74VHCT08AFT
IC904 00D 263 0896 909 NJM2068MD-TE1 +C
IC971,972 00D 262 3446 900 TC4052BFT
TR501 00D 271 0301 903 KTA1268-BL-AT/P
TR502 00D 274 0160 907 2SD2144STPU
TR503 00D 271 0301 903 KTA1268-BL-AT/P
TR504 00D 273 0458 904 KTC3200-BL-AT/P
TR505 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR506 00D 271 0301 903 KTA1268-BL-AT/P
TR507 00D 273 0458 904 KTC3200-BL-AT/P
TR509 00D 274 0160 907 2SD2144STPU
TR510,511 00D 271 0301 903 KTA1268-BL-AT/P
TR512-516 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR519-526 00D 273 0460 905 KTC2875-B-RTK/P
TR531-538 00D 273 0460 905 KTC2875-B-RTK/P
TR543,544 00D 271 0301 903 KTA1268-BL-AT/P
TR548 00D 271 0301 903 KTA1268-BL-AT/P
TR701,702 00D 273 0460 905 KTC2875-B-RTK/P
TR703-705 00D 273 0464 901 KTC3875S-GR-RTK/P
TR706 00D 269 0191 903 KRA104S-RTK/P (47K-47K)
TR707 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR708 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR709 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR710 00D 271 0326 904 2SA1954(B)-TE85L
TR711,712 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR713 00D 271 0326 904 2SA1954(B)-TE85L
TR716 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR717 00D 271 0326 904 2SA1954(B)-TE85L
TR801 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR802 00D 271 0326 904 2SA1954(B)-TE85L
TR971 00D 269 0191 903 KRA104S-RTK/P (47K-47K)
TR972 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
D501-510 00D 276 0856 903 RB500V-40
D511 00D 276 0794 900 KDS160-RTK/P
D512-515 00D 276 0856 903 RB500V-40
D516 00D 276 0794 900 KDS160-RTK/P
D517-519 00D 276 0704 903 1SR35-400A(T93X)
D701,702 00D 276 0794 900 KDS160-RTK/P
D703 nsp RM73B--0R0KT +2125
D704,705 00D 276 0704 903 1SR35-400A(T93X)
D706 nsp RM73B--0R0KT +2125
ZD704 00D 276 0459 915 HZS5B-2TD
RESISTORS GROUP
R512 00D 241 2383 902 RD14B2E223JNBST
R529 00D 241 2383 902 RD14B2E223JNBST
R741,742 00D 241 2387 908 RD14B2E010JNBST
CAPACITORS GROUP
C101-106 nsp CK73B1H103KT (1608) +1608
C107,108 nsp RM73B--0R0KT +1608
C109 00D 254 4573 981 CE04W1H100MT(RA3)
C110-114 nsp RM73B--0R0KT +1608
