Denon AVR-3808CI Service Manual

173
AVR-3808CI / AVR-3808 / AVC-3808
49 00D GEN 8568 -1 TOP COVER SUB ASSY SRE2,E2A,EUT,E1C,JP : 102 0704 013 1
★50
nsp LICENSE SUB ASSY 1
★51
nsp SERIAL NO. SHEET 1
52 nsp SCREW COVER 1
53 nsp PUSH RIVET NRP-345 1
★54
nsp FUSE CAUTION LABEL 1
56 nsp SIDE BRACKET BKE2,SRE2,E2A,EUT,E1C 1
57 nsp SP RIVET BKE2,SRE2,E2A,EUT,E1C 18
★58
nsp MAC ADDRESS SUB ASSY 1
60 00D 146 2509 106 INNER PANEL EU,EC,BKE2 1 *
60 00D 146 2509 119 INNER PANEL SRE2 1 *
60 00D 146 2509 122 INNER PANEL E2A,EUT,E1C,JP 1 *
61 00D 143 1293 100 DOOR SHEET EU,EC,BKE2 1 *
61 00D 143 1293 113 DOOR SHEET SRE2 1 *
61 00D 143 1293 126 DOOR SHEET E2A,EUT,E1C,JP 1 *
62 nsp RUBBER SHEET DOOR CLOSE 2
63 nsp RUBBER SHEET DOOR OPEN 2
64 00D 143 1294 002 WINDOW 1 *
65 00D 113 1996 202 CURSOR KNOB EU,EC,BKE2 1
65 00D 113 1996 215 CURSOR KNOB SRE2 1
65 00D 113 1996 231 CURSOR KNOB E2A,EUT,E1C,JP 1
66 00D 113 1995 041 ENTER KNOB EU,EC,BKE2 1
66 00D 113 1995 012 ENTER KNOB SRE2 1
66 00D 113 1995 038 ENTER KNOB E2A,EUT,E1C,JP 1
67 nsp LENS (POWER) 1
68 00D 113 1992 109 P.KNOB ASSY(SUB) EU,EC,BKE2 1
68 00D 113 1992 112 P.KNOB ASSY(SUB) SRE2 1
68 00D 113 1992 138 P.KNOB ASSY(SUB) E2A,EUT,E1C,JP 1
69 00D 113 1994 107 P.KNOB ASSY(MAIN) EU,EC,BKE2 1
69 00D 113 1994 110 P.KNOB ASSY(MAIN) SRE2 1
69 00D 113 1994 136 P.KNOB ASS'Y(MAIN) E2A,EUT,E1C,JP 1
70 nsp USB BRACKET 1
71 00D 421 0763 010 GEAR DAMPER 058E-L 1
72 nsp DOOR STOPPER 1
73 nsp BKT2 UNIT (Cut A.VIDEO UNIT P.W.B.) 1
74 nsp BKT1 UNIT (Cut A.VIDEO UNIT P.W.B.) 1
75 nsp D/S PLATE (Cut INNER PANEL) 1
76 nsp FRONT CHASSIS 1 *
77 00D 144 3027 005 FRONT PANEL EU,EC 1 *
77 00D 144 3027 034 FRONT PANEL BKE2 1 *
77 00D 144 3027 018 FRONT PANEL SRE2 1 *
77 00D 144 3027 050 FRONT PANEL E1C 1 *
77 00D 144 3027 021 FRONT PANEL E2A,EUT 1 *
77 00D 144 3027 047 FRONT PANEL JP 1 *
78 nsp FRONT BRACKET 1 *
79 nsp DENON BADGE EU,EC,BKE2 1
79 nsp DENON BADGE SRE2 1
79 nsp DENON BADGE E2A,EUT,E1C,JP 1
80 nsp LENS 3
81 00D 144 3029 003 DOOR ASSY EU,EC 1 *
81 00D 144 3029 032 DOOR ASSY BKE2 1 *
81 00D 144 3029 016 DOOR ASSY SRE2 1 *
81 00D 144 3029 058 DOOR ASSY E1C,EUT 1 *
81 00D 144 3029 029 DOOR ASSY E2A 1 *
81 00D 144 3029 045 DOOR ASSY JP 1 *
82 00D 401 0195 202 HINGE (L) EU,EC,BKE2 1
Ref. No. Part No. Part Name Remarks Q'ty New
