Denon AVR-3808CI Service Manual

122
AVR-3808CI / AVR-3808 / AVC-3808
Except for Japan model
C822-829 nsp CK73B1E104KT +1608
C831 nsp CK73B1E104KT +1608
C934 nsp CC73CH1H101JT +1608
C935 nsp CK73B1H103KT (1608) +1608
C936 nsp CK73B1E104KT +1608
C937 nsp CC73CH1H101JT +1608
C938 nsp CK73B1H103KT (1608) +1608
C939 nsp CK73B1E104KT +1608
C941,942 nsp CC73CH1H101JT +1608
C943 00D 254 4524 985 CE04W1H100MT SMG/RE3
C944-948 nsp CK73B1E104KT +1608
CC402 00D 254 4524 985 CE04W1H100MT SMG/RE3
CC403,404 nsp CK73B1H103KT (1608) +1608
CC702 nsp CK73B1H103KT (1608) +1608
CC707 00D 254 4524 985 CE04W1H100MT SMG/RE3
CC709 nsp CK73B1H103KT (1608) +1608
CC712 00D 254 4536 928 CE04W1A101MT SMG/RE3
CC714 00D 254 4536 928 CE04W1A101MT SMG/RE3
CC715 nsp CK73B1E104KT +1608
CC716-718 00D 254 4524 985 CE04W1H100MT SMG/RE3
CC719 nsp CK73B1E104KT +1608
CC720 nsp CK73B1H103KT (1608) +1608
CC721-723 00D 254 4536 928 CE04W1A101MT SMG/RE3
CC724 00D 254 4327 904 CE04W0J102MT(SMG)
OTHERS PARTS GROUP
CW054 nsp 5P CON.SOCKET TUC-P
CW082 nsp 8P CON.SOCKET(TUC-P)
CW092 nsp 9P SOCKET(9120)
CW102 nsp 10P CON.SOCKET TUC-P
CW112,113 nsp 11P SOCKET(9120)
CW132 nsp 13P SOCKET(9120)
CW962 nsp 6P CON.SOCKET(TUC-P
CX044 nsp 4P CON.BASE(TUC-P)
CX053 nsp 5P PH CON.BASE(L) +REF
CX054 nsp 5P CON.BASE TUC-P
CX072 nsp 7P CONN.BASE(KR-PH)
CX092,093 nsp 9P PIN HEADER(9120)
CX112-115 nsp 11P PIN HEADER(9120)
CX132,133 nsp 13P PIN HEADER(9120)
CX171 00D 205 1100 038 17P FFC BASE(P=1)
CX903 nsp 9P D-SUB CONNECTOR
CX960 nsp 6P CON.BASE(TUC-P)
CY271 00D 205 1329 000 27P FFC BASE(9610SB)
FB501 00D 235 0049 900 BEADS INDUCTOR TAPE
FB701 00D 235 0147 909 E.FIL(BLM21PG221SN1)+2125
FB901,902 nsp RM73B--0R0KT +1608
JK401-403 00D 204 8745 011 6P S&PIN JACK(NI)
JK404 00D 204 8736 017 1P PIN JACK(FG/NI-YEL)
JK601,602 00D 204 8743 013 6P PIN JACK(FG/NI-GBR)
JK701 00D 205 0906 000 1P S-TERMINAL(AU.SW)
JK703 00D 204 8260 004 MINI JACK
JK704 00D 205 1381 006 USB CONNECTOR
JK707 00D 204 8730 000 3P PINJACK(BK/AU)
JK708 00D 204 8744 025 3P PIN JACK(FG/NI-GBR)
JK801 00D 204 8744 012 3P PIN JACK(FG/NI-ORG)
L501 00D 235 0150 941 LQH32MN330J23L
W701-703 nsp M3 SCREW TERMINAL
Ref. No. Part No. Part Name Remarks Q'ty New
